Product Description
The BWT beam combining fiber laser boasts exceptional beam quality, enabling precise processing capabilities. It offers a variety of continuous and regulated pulse modes, allowing users to select the most suitable option and effectively reducing the heat-affected zone during processing. With its reliable performance and fully modularized fiber design, all photoelectric devices are securely enclosed within a sturdy housing, ensuring durability even in demanding industrial conditions. This laser technology finds wide application in fields such as precise processing, 3D printing, sheet metal processing, and Lithium-ion battery processing. It is capable of processing diverse materials, including various steels, aluminum and nickel-based alloys, titanium alloys, and alumina ceramics. To inquire about our products or request a quotation, please don’t hesitate to contact us.
Product Features
- Simple control interface.
- Excellent system stability.
- Fiber laser sources with good beam quality, suitable for precision machining.
- There are two modes of continuous and modulated pulse to optimize the machining quality.
Product Parameters
| Power | 500W |
| Wavelength | 1080±10 nm |
| Output fiber core diameter | 14μm/20μm/50μm |
| Cable Length | 12 m or Customized |
| Beam Delivery | QBH or Customized |
| Guide Beam | Red |
| Operation Mode | Continuous or Modulated |
| Polarization | Random |
| (25℃)Power Stability | ＜±1.5% (2h) |
| Power Adjustment Scope | 10%-100% |
| Max. Modulation Frequency | 5kHz |
| Weight | ＜30Kg |
| Outline Feature | 100mm*482mm*347mm |
| Voltage | 220±20V,AC,PE,50/60Hz |
| Power Consumption | 1.5kW |
| Control Interface | RS232 |
| Mini. Water Cooling Capacity | 1 kW |
| Temperature Settings | 25℃（Laser Module），30℃（QBH） |
| Cooling Tubes Size (External) | Φ12mm |
| Cooling Water Flux | >5L/min |
| QBH Cooling Water Flux | 1.5~2.0L/min |
