Product Features
1. Diversity optical connector.
2. Apply with a closed-loop Servo stepping motor, to avoid the step losing effectively.
3. High precision, high-speed positioning system.
4. Apply with a drawer-type mirror seat, which is convenient to replace protective lenses.
5. Great improve in the cutting and perforation speed.
Product Paramenters
Max. laser power
|
4 kW (2D version only)
|
Collimating focal length
|
100 mm, Focus lengths: 125, 150, 200 mm
|
Dimensions (WXD)
|
130 x 69 mm
|
Weight
|
4.0 kg
|
