Product Introduction
Our Industrial Robot Laser Welder, designed for unparalleled welding speeds, efficiency, and output. Experience faster manufacturing times and reduced costs for enterprises. The Industrial Robot Laser Welder guarantees stable performance through its precise control system, ensuring accurate and consistent movements during operation. This allows for precise and repeatable actions, perfect for applications demanding high levels of accuracy and consistency. Elevate your welding capabilities with our cutting-edge robotic solution and achieve unmatched precision and productivity. Experience the future of welding technology and take your business to new heights. Contact us for more product information.
Advantages
- Can be onerated 24 hours. effectively save labor costs. in addition, the use of industrial manipulator operation mode, and automatic assembly line to save the site. so that the whole plant planning more compact.
- Manipulator production of a product time is fixed within the same production cycle, the output is fixed product yield is high, high production benefits.
- Production operation, high precision high stability, can guarantee personnel, instead of manual dangerous operations.
- It is suitable for hardware processing, automobile accessories, furniture accessories. heating pipe welding embedded parts.etc.
Parameters
| Model | RL-R1512 |
| Number of axes | 6 axis |
| Radius of motion | 1550mm |
| Payload | 10KG |
| Degree of protection | J1, J2 axis IP56 (J3, J4, J5, J6 axis IP67) |
| Installation method | Floor, wall-mounted, tilted, upside-down |
| Battery capacity | 4.5KVA |
| Input/output signal | Standard 16 in/16 out 24VDC |
| Robot weight | 172KG |
| Repeatability | +0.05 |
| Range of motion | / |
| 1 axis S | ±160° |
| 2 axis L | +80 to -145° |
| 3 axis U | +145° to -75° |
| 4 axis R | +190° |
| 5 axis B | +50 to -210° |
| 6 axis T | ±360° |
| Movement speed | / |
| 1 axis S | 257°/s |
| 2 axis L | 223°/s |
| 3 axis U | 223°/s |
| 4 axis R | 392°/s |
| 5 axis B | 275°/s |
| 6 axis T | 540°/s |
| Application field | Loading and unloading, spraying, handling, packaging, cutting |
| 4 axis R(N.m) | 103.5 |
| 5 axis S(N.m) | 51.84 |
| 6 axis T(N.m) | 32.64 |
| Built-in trachea | Φ10 |
|
Installation environment |
Temperature 0-45°C,Humidity 20~80%RH (no condensation) vibration acceleration below 4.9m/S (0.5G) altitude below 1000m |
| Other non-flammable, corrosive gases, liquids, no splashing water, less oil, dust away from electromagnetic sources and away from magnetic fields |
FAQ
1.How long is the warranty period?
Whole machine warranty period is 1 year, laser source 2 years. If there is any problem during the period, we will solve it as soon as possible.
2.Packaging
All our machines are packed in wooden boxes.
3.Language interface
Supports language customization, etc. You can also translate and insert to software.
